Nacelle cranes guarantee maximum manoeuvrability with a huge range of different working positions. The crane enables safe and fast lifting from the platform to the nacelle and between heli-deck and the nacelle. Its compact design is the perfect fit for areas with limited working space.



  • Overload protection system
  • Hydraulic operated rope winch
  • Hoisting speed: 15m/min*
  • Wire rope, rotation free, galvanised
  • Hydraulic operated slewing drive
  • Electric power requirements: 24 V DC
  • Required Oil flow: 6 – 100l/min
  • Pressure: 200-310 bar
  • Cable or radio remote control system
  • Protection class IP56
  • Stainless steel components
  • Nickle chrome or stainless steel piston rods
  • Surface protection
  • Compact storage position


  • Man-riding function*
  • Endless slewing*
  • Visual warning light
  • LED working light
  • Acoustic warning system

All points marked * Not applicable for PC1500
